CRD600 Automatic Fitting Inserter

MWcms on February 22, 2024

CRD600 CE Cover Photo Mod 400x354 1 <div class="callemail nomobile"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">email</a> with questions.</strong></h3> </div> <div class="callemail nodesktop"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">Email</a> with Questions </strong></h3> </div> <div class="wp-block-buttons"> <!-- /wp:button --> </div>
CRD600SSCover 290x300 1 <div class="callemail nomobile"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">email</a> with questions.</strong></h3> </div> <div class="callemail nodesktop"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">Email</a> with Questions </strong></h3> </div> <div class="wp-block-buttons"> <!-- /wp:button --> </div>
CRD600AF 294x300 1 <div class="callemail nomobile"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">email</a> with questions.</strong></h3> </div> <div class="callemail nodesktop"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">Email</a> with Questions </strong></h3> </div> <div class="wp-block-buttons"> <!-- /wp:button --> </div>
CRD 610 CE Manual 342x300 1 <div class="callemail nomobile"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">email</a> with questions.</strong></h3> </div> <div class="callemail nodesktop"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">Email</a> with Questions </strong></h3> </div> <div class="wp-block-buttons"> <!-- /wp:button --> </div>

Call or email with questions.

Call or Email with Questions

The CRD600 Automatic Fitting Inserter is an ergonomic assembly device that inserts a fitting into the end of a flexible tube.

Download

CRD400 600jaws <div class="callemail nomobile"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">email</a> with questions.</strong></h3> </div> <div class="callemail nodesktop"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">Email</a> with Questions </strong></h3> </div> <div class="wp-block-buttons"> <!-- /wp:button --> </div> [wptabs id="369"]
Fitting Inserter Jaws

P/N: FIJ### (O.D. of the tubing)
Fitting inserter jaws are machined from natural Delrin and are sized to accommodate the O.D. of a wide range of industry standard tubing. Available sizes: 3/32″ – 9/16″. Please specify the tubing O.D. when ordering so we may provide you with the best fit.
600mag 1 <div class="callemail nomobile"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">email</a> with questions.</strong></h3> </div> <div class="callemail nodesktop"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">Email</a> with Questions </strong></h3> </div> <div class="wp-block-buttons"> <!-- /wp:button --> </div> [wptabs id="369"]
Fitting Inserter Magazine

P/N: ATMA
Magazines are custom made based on fitting requirements.
600pinset 1 <div class="callemail nomobile"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">email</a> with questions.</strong></h3> </div> <div class="callemail nodesktop"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">Email</a> with Questions </strong></h3> </div> <div class="wp-block-buttons"> <!-- /wp:button --> </div> [wptabs id="369"]
Fitting Inserter Pinset

P/N: ATPS
Pinsets are custom made based on fitting requirements.
NAPS24 <div class="callemail nomobile"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">email</a> with questions.</strong></h3> </div> <div class="callemail nodesktop"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">Email</a> with Questions </strong></h3> </div> <div class="wp-block-buttons"> <!-- /wp:button --> </div> [wptabs id="369"]
Power Supply

P/N: NAPS24
Class 2 AC to DC Transformer, 2.1mm ID x 5.5mm OD, input= 120VAC-230VAC 60 Hz 20W, output= 24VDC 1000mA, 6′ cord, 2 prong plug, UL Listed.
EUPS24 <div class="callemail nomobile"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">email</a> with questions.</strong></h3> </div> <div class="callemail nodesktop"> <h3><strong><a href="tel:3034380853">Call</a> or <a href="mailto:sales@cleanroomdevices.com">Email</a> with Questions </strong></h3> </div> <div class="wp-block-buttons"> <!-- /wp:button --> </div> [wptabs id="369"]
European Power Supply

P/N: EUPS24
Class 2 AC to DC Transformer, 2.1mm ID x 5.5mm OD, input= 90 VAC ~ 264 VAC 30W, output= 24VDC 1250mA, 5’ cord, 5 plug types.
SKU: N/A Category:

Description

The CRD600 Automatic Fitting Inserter is an ergonomic assembly device that inserts a fitting into the end of a flexible tube. This barbed fitting inserter uses smart relay technology and pneumatic action to achieve precise repeatable action. Throughput will improve and repetitive stress hand injuries will decrease. An optional alcohol dispenser is available.

CE Certified: The CRD600 is now available as a CE certified model.

Please contact us for pricing and availability (303) 438-0853 or Email our Sales Department

CRD600_CE_Cover_Photo_Mod

Technical Specifications

  • Accommodates tubing from 3/32” to 9/16” O.D.
  • Designed for all straight fittings.
  • Throughput of 400-800 units per hour; with bowl feeder, 1500-1800 units per hour.
  • Magazine loaded; adaptable to a bowl feeder.
  • 2-minute downtime to reconfigure for a different fitting/tubing combination.
  • Compatible with most flexible tubing.
  • Accommodates tubing from 3/32” to 9/16” O.D.
  • Designed for all straight fittings.
  • Throughput of 400-800 units per hour; with bowl feeder, 1500-1800 units per hour.
  • Magazine loaded; adaptable to a bowl feeder.
  • 2-minute downtime to reconfigure for a different fitting/tubing combination.
  • Compatible with most flexible tubing.
  • Power supplies for both North America (120VAC) and Europe (230VAC) to be specified at the time of order.
  • Optional alcohol dispenser is available.
  • 90 days parts and labor warranty; see user’s manual for warranty details.

Additional information

Model

CRD600, CRD600SS (Stainless Steel Cover), CRD600AF (Automatic Fitting Inserter with Vibratory Bowl), CRD610 (Large Fitting Inserter)
